Item Name Description
1 USB connector
2 DVD tray
3 DVD activity LED
4 Tray open/close button
5 Manual tray release
6 Health LED Green = OK
Flashing yellow = Critical error
7 UID LED Blue = UID on
OA GUI
The OA GUI provides partition status and FRU information. For more information on using the OA GUI,
see the HPE Integrity Superdome X and Superdome 2 Onboard Administrator User Guide.
NOTE:
CAE events and errdump information is not available using the GUI. You must use the command
line for this information.
Health Repository viewer
The Health Repository User Interface displays the information from the HR database. The HR database
contains current state and history covering both service events and the results of error events analysis.
The following information is available in the HR display:
• Description of each failure event on the system that results in a service request, even after a
component is removed or replaced.
• History of component identities.
Information in the HR database is stored as installation and action records. These records are organized
with component physical location as the key.
Indictment Records
Indictment refers to a record specifying that a component requires service. The component or a
subcomponent might or might not be deconfigured as a result. Each indictment record contains the
following information:
• The time of the error.
• The cause of the error.
• The subcomponent location of the error (when analysis allows).
In cases when the failing component cannot be identified with certainty, analysis indicts the most probable
component that will need to be replaced to solve the problem. Other components that might have been
responsible can be identified as suspects by writing a suspicion record. A suspicion record contains the
same fields as an indictment record.
OA GUI 63
