HP Integrity Superdome X User Manual

GPSM subcomponent displays
- SubFru Isolation -
- GPSM -
- CAMNet Ports -
1 - 2 - 3 - 4 - 5 - 6 - 7 - 8
SW Port: 0 0 0 0 0 0 0 0
Blade: 0 0 0 0 0 0 0 0
OA: 0 0 . . . . . .
XFM: 0 0 0 0 . . . .
Other GSPM: 0 . . . . . . .
FPGA: 0 . . . . . . .
---
OA subcomponent display
- SubFru Isolation -
- OA -
- CAMNet Ports -
-A- -B-
Port: 0 1
---
XFM subcomponent display
- SubFru Isolation -
- XFM -
- Fabric Ports -
0- 1- 2- 3- 4- 5- 6- 7- 8- 9-10-11-12-13-14-15-16-17-18-19
Upper: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0
Lower: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0
------------------------------------------------------------------
VRM: Fault
---
VRMs reported by this display are as follows:
• V3P3_STBY
• V2P5_STBY
• V1P2_STBY
• V1P8_0
• V1P8_1
• V1P2
• CAMNET_A
• CAMNET_B
Using event logs
Event logs are generated by software or firmware when an event is detected. Some events that cause
event records to be generated are as follows:
• Hardware-related.
◦ Example: DIMM, CPU, VRM, XNC, or PCI-BUS failures.
• Software-related.
◦ Example: indicating that firmware or software reached a certain point in the code, or that a certain
amount of time has passed, for example when a QPI LINK has a timeout.
72 GPSM subcomponent displays
