Internal and external site door requirements
Internal site doorways must obey the following height requirements:
• For the 642 1075 mm rack — no less than 200.19 cm (78.816 in)
• For the 642 1200 mm rack — no less than 200.66 cm (79.00 in)
To account for the lifted height of the pallet, external doorways must obey the following height
requirements:
• For the 642 1075 mm rack — no less than 216.80 cm (85.35 in)
• For the 642 1200 mm rack — no less than 215.00 cm (84.65 in)
More information
Generic Site Preparation Guide
Electrical specifications
Table 4: Enclosure power options
Source type Source voltage
(nominal)
Plug or
connector type
Circuit type Power
receptacle
required
Number of
power cords
required (per
enclosure)
3–phase 200 VAC to 240
VAC line-to-line
(phase-to-
phase), 3-
phase
50/60 Hz
NEMA L15-30p,
3-Pole, 4-wire,
3 m (10 ft)
power cord
30 A 3-phase L15-30R. 3-
pole, 4-wire
4
3–phase 220 VAC to 240
VAC line-to-
neutral 3-phase
50/60 Hz
IEC 309, 4-
pole, 5-wire,
Red, 3 m (10 ft)
power cord
16 A IEC 309, 4-
pole, 5-wire, red
4
Single-phase 200 VAC to 240
VAC
50/60 Hz
IEC 320
C19-C20
16/20 A Single-
phase
IEC 320
C19
12
Table 5: Single-phase power cords
Part number Description Where used
8120-6895 Stripped end, 240 V International - other
8120-6897 Male IEC309, 240 V International
8121-0070 Male GB-1002, 240 V China
8120-6903 Male NEMA L6-20, 240 V North America/Japan
Internal and external site door requirements 25
