28 LISY OF SYMBOLS 117
28.1 Yellow and orange symbols
Yellow and orange symbols indicate an error condition that requires prompt intervention. Active driving aids are also represented by
yellow or orange symbols.
FI warning lamp (MIL) lights up/flashes orange – The OBD has detected an emission- or safety-critical fault.
The low fuel warning lamp lights up orange – The fuel level has reached the reserve mark.
28.2 Green and blue symbols
Green and blue symbols reflect information.
The high beam indicator light lights up blue – The high beam is switched on.
Turn signal indicator light flashes green – The turn signal is switched on.
