12 SERVICE WORK ON THE CHASSIS 48
12.13 Lubricating the steering head bearing
800010-10
– Remove the lower triple clamp. ( p. 44)
– Install the lower triple clamp. ( p. 45)
12.14 Removing the front fender
Preparatory work
– Switch off all power consumers and switch off the engine.
– Remove the headlight mask with the headlight. ( p. 85)
H00235-10
Main work
–
Remove screws
and
. Remove the front fender.
12.15 Installing the front fender
H00181-10
Main work
–
Position the front fender. Mount and tighten screws
and
.
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Finishing work
– Install the headlight mask with the headlight. ( p. 86)
