4 VIEW OF VEHICLE 11

4.2 View of vehicle, rear right (example)

H00209-10

1 Fork compression adjustment

2 Kill switch ( p. 14)

2 Horn button ( p. 15)

2 Light switch ( p. 15)

2 Turn signal switch ( p. 15)

3 Emergency OFF switch ( p. 15)

3 Electric starter button ( p. 16)

4 Throttle grip ( p. 14)

5 Fork rebound adjustment

6 Foot brake lever ( p. 18)

7 Level viewer, engine oil

8 Shock absorber rebound adjustment

9 Level viewer for brake fluid, rear

10 Shock absorber compression adjustment

Default Chapter4
- Table of Contents4
1 Means of Representation7
- Symbols Used7
- Formats Used7
2 Safety Advice8
- Use Definition - Intended Use8
- Degrees of Risk and Symbols8
- Tampering Warning8
- Safe Operation9
- Protective Clothing9
- Work Rules9
- Environment9
- Owner's Manual10
3 Important Notes11
- Manufacturer and Implied Warranty11
- Operating and Auxiliary Substances11
- Spare Parts, Accessories11
- Service11
- Figures11
- Customer Service11
4 View of Vehicle12
- View of Vehicle, Front Left (Example)12
- View of Vehicle, Rear Right (Example)13
5 Serial Numbers14
- Chassis Number14
- Type Label (FE EU/AU)14
- Key Number (FE EU/AU)14
- Engine Number14
- Fork Part Number14
- Shock Absorber Article Number15
6 Controls16
- Clutch Lever16
- Hand Brake Lever16
- Throttle Grip16
- Kill Switch (FE EU/AU)16
- Kill Switch (FE US)16
- Horn Button (FE EU/AU)17
- Light Switch (FE EU/AU)17
- Light Switch (FE US)17
- Turn Signal Switch (FE EU/AU)17
- Emergency off Switch (FE AU)17
- Electric Starter Button (FE EU/US)18
- Electric Starter Button (FE AU)18
- Overview of Indicator Lamps (FE EU/AU)18
- Overview of Indicator Lamps (FE US)18
- Opening the Filler Cap18
- Closing the Filler Cap19
- Idle Speed Adjusting Screw20
- Shift Lever20
- Foot Brake Lever20
- Side Stand21
- Steering Lock (FE EU/AU)21
- Locking the Steering (FE EU/AU)21
- Unlocking the Steering (FE EU/AU)22
7 Speedometer23
- Overview23
- Activation23
- Message on the Speedometer23
- Setting the Speedometer23
- Setting the Kilometers or Miles24
- Setting the Clock25
- Setting the Service Display25
- Speed, Time, and DST Distance 126
- Speed, Time, and DST2 Distance 226
- AVG Average Speed, ART Operating Hours, and ODO Total Distance Covered26
8 Preparing for Use27
- Advice on First Use27
- Running-In the Engine28
- Preparing the Vehicle for Difficult Riding Conditions28
- Preparing for Rides on Dry Sand29
- Preparing for Rides on Wet Sand29
- Preparing for Rides on Wet and Muddy Surfaces30
- Preparing for Rides at High Temperature and Slow Speed30
- Preparing for Rides at Low Temperature or in Snow30
9 Riding Instructions31
- Preparing for Use31
- Starting31
- Starting off32
- Shifting, Riding32
- Braking32
- Stopping, Parking33
- Transport33
- Refueling34
- Service Schedule35
10 Service Schedule36
- Service Work (as Additional Order)36
11 Tuning the Chassis37
- Tuning the Chassis37
- Checking the Basic Chassis Setting with the Rider's Weight37
- Compression Damping of Shock Absorber37
- Adjusting the Low-Speed Compression Damping of the Shock Absorber37
- Adjusting the High-Speed Compression Damping of the Shock Absorber38
- Adjusting the Rebound Damping of the Shock Absorber38
- Measuring Rear Wheel Sag Unloaded39
- Checking the Static Sag of the Shock Absorber39
- Checking the Riding Sag of the Shock Absorber39
- Adjusting the Spring Preload of the Shock Absorber40
- Adjusting the Riding Sag41
- Checking Basic Setting of Fork41
- Adjusting the Compression Damping of the Fork42
- Adjusting the Rebound Damping of the Fork42
- Handlebar Position42
- Adjusting the Handlebar Position43
12 Service Work on the Chassis44
- Raising the Motorcycle with a Lift Stand44
- Removing the Motorcycle from the Lift Stand44
- Bleeding the Fork Legs44
- Cleaning the Dust Boots of the Fork Legs44
- Removing the Fork Protector45
- Installing the Fork Protector45
- Removing the Fork Legs45
- Installing the Fork Legs46
- Removing the Lower Triple Clamp46
- Installing the Lower Triple Clamp47
- Checking the Steering Head Bearing Play49
- Adjusting the Steering Head Bearing Play49
- Lubricating the Steering Head Bearing50
- Removing the Front Fender50
- Installing the Front Fender50
- Removing the Shock Absorber51
- Installing the Shock Absorber51
- Removing the Seat51
- Mounting the Seat52
- Removing the Air Filter Box Lid52
- Installing the Air Filter Box Lid52
- Removing the Air Filter53
- Installing the Air Filter53
- Cleaning the Air Filter and Air Filter Box53
- Sealing the Air Filter Box54
- Removing the Manifold54
- Installing the Manifold56
- Removing the Main Silencer57
- Cleaning the Spark Arrestor (FE US)58
- Installing the Main Silencer59
- Changing the Glass Fiber Yarn Filling of the Main Silencer59
- Removing the Right Side Cover60
- Installing the Right Side Cover60
- Removing the Fuel Tank61
- Installing the Fuel Tank62
- Checking for Chain Dirt Accumulation63
- Cleaning the Chain63
- Checking the Chain Tension64
- Adjusting the Chain Tension64
- Checking the Chain, Rear Sprocket, Engine Sprocket and Chain Guide65
- Checking the Frame67
- Checking the Swingarm67
- Checking the Routing of the Throttle Cable67
- Checking the Rubber Grip68
- Additionally Securing the Rubber Grip68
- Adjusting the Basic Position of the Clutch Lever68
- Checking/Rectifying the Fluid Level of the Hydraulic Clutch68
- Changing the Hydraulic Clutch Fluid69
- Removing the Engine Guard69
- Installing the Engine Guard69
13 Brake System70
- Checking Free Travel of Hand Brake Lever70
- Adjusting Free Travel of Hand Brake Lever (FE EU/AU)70
- Adjusting the Basic Position of the Hand Brake Lever (FE US)70
- Checking the Brake Discs71
- Checking the Front Brake Fluid Level71
- Adding Front Brake Fluid71
- Checking the Front Brake Linings72
- Changing the Front Brake Linings73
- Checking the Free Travel of Foot Brake Lever74
- Adjusting the Basic Position of the Foot Brake Lever75
- Checking the Rear Brake Fluid Level75
- Adding Rear Brake Fluid76
- Checking the Rear Brake Linings77
- Changing the Rear Brake Linings77
14 Wheels, Tires79
- Removing the Front Wheel79
- Installing the Front Wheel79
- Removing the Rear Wheel80
- Installing the Rear Wheel81
- Checking the Tire Condition81
- Checking the Tire Air Pressure82
- Checking Spoke Tension82
15 Electrical System84
- Removing the Battery84
- Installing the Battery84
- Charging the Battery85
- Changing the Main Fuse86
- Changing the Fuses of Individual Power Consumers86
- Removing the Headlight Mask with the Headlight87
- Installing the Headlight Mask with the Headlight88
- Changing the Headlight Bulb89
- Changing the Turn Signal Bulb90
- Checking the Headlight Setting90
- Adjusting the Headlight Range91
- Changing the Speedometer Battery91
16 Cooling System92
- Checking the Antifreeze and Coolant Level92
- Checking the Coolant Level93
- Draining the Coolant93
- Refilling Coolant94
17 Tuning the Engine95
- Checking the Play in the Throttle Cable95
- Adjusting the Play in the Throttle Cable95
- Adjusting the Idle Speed96
- Checking the Basic Position of the Shift Lever96
- Adjusting the Basic Position of the Shift Lever96
18 Service Work on the Engine98
- Changing the Fuel Screen98
- Checking the Engine Oil Level98
- Changing the Engine Oil and Oil Filter, Cleaning the Oil Screens99
- Adding Engine Oil101
19 Cleaning, Care102
- Cleaning the Motorcycle102
- Checks and Maintenance Steps for Winter Operation103
20 Storage104
- Preparing for Use after Storage104
21 Troubleshooting105
22 Blink Code107
23 Technical Data109
- Engine109
- Engine Tightening Torques109
- Capacities111
- Engine Oil111
- Coolant111
- Fuel111
- Chassis111
- Electrical System112
- Tires112
- Fork112
- Shock Absorber113
- Chassis Tightening Torques113
24 Substances115
25 Auxiliary Substances116
26 Standards117
27 List of Abbreviations118
28 Lisy of Symbols119
- Yellow and Orange Symbols119
- Green and Blue Symbols119
- Index120
