The following illustration shows the internal routing for the configuration cable.
Removing and replacing consumable parts and Tier 1 CRUs
Replacement of consumable parts and Tier 1 CRUs is your responsibility. If IBM
installs a consumable part or Tier 1 CRU at your request, you will be charged for
the installation.
The illustrations in this document might differ slightly from your hardware.
176 IBM System x3650 M3 Types 4255, 7945, and 7949: Problem Determination and Service Guide
