DSC MENU OPERATION
2001 NEW
■ General
Up to 100 ID codes with frequency and name can be
programmed in MENU mode for easy recall during
DSC call setting.
In addition, the following settings/operation are avail-
able in DSC setup menu.
• Manual position/time setting (p. 16)
•Self-ID (MMSI code) indication (described in this sec-
tion)
■ ID input
A total of 100 ID codes can be programmed as “Ad-
dress ID” (for ships and coast stations) and “Group ID”
(for group stations). A pair of frequencies (both transmit
and receive) and ID name are also programmed to-
gether with the ID code which are used as call fre-
quencies when using the ID code.
DD
SETTING PROCEDURES:
q During DSC menu indication, rotate [CH] to select
“Set up” then push [ENT] to select setup menu.
• The select screen is displayed as below.
w Rotate [CH] to select the “Address ID” or
“Group ID,” then push [ENT].
• The address/group ID list screen is displayed.
When the memory is full:
“Memory full” is displayed beside “<add>”
indication when 100 ID codes have been pro-
grammed.
Delete any unnecessary IDs in such cases (see p.
46 for delete).
e Rotate [CH] to select “<add>” then push [ENT].
• The address/group ID setup screen is displayed.
r Push the numeral keys to input the desired 10-digit
ID name, 9-digit code and both transmit and re-
ceive frequencies, then push [ENT].
• Rotate [CH] to move the cursor.
•When entering group code, enter “0 (zero)” for the first
digit.
•The frequencies entered should be within the marine
frequency ranges as follows.
1.6– 2.9999 MHz 4.0– 4.9999 MHz
6.0– 6.9999 MHz 8.0– 8.9999 MHz
12.0–13.9999 MHz 16.0–17.9999 MHz
18.0–19.9999 MHz 22.0–22.9999 MHz
25.0–27.5000 MHz
t Push [ENT] to program the contents into the ad-
dress or group ID.
•
Returns to the address/group ID list screen automati-
cally.
•The ID list is displayed in alphabetical order for ID
name, so [CH] rotation may be necessary for the pro-
grammed ID confirmation.
y Push [MODE SET ] to return to DSC watch mode,
or push [FREQ/CH] to return to the select screen.
******** Set up ********
------
Address ID ------
******** Set up ********
-------
Group ID -------
<add>
ICOM
M802 012345678
SEL
OK
Ç
Cancel
******** Set up ********
------
Address ID ------
********
Set up ********
-------
Group ID -------
Name:ICOM_M802_
ID:012345678
TX:_2345.0kHz
RX:_2345.0kHz
SEL
OK
Cancel
******** Set up ********
------
Address ID ------
******** Set up ********
-------
Group ID -------
Name:
† _________
ID:0________
TX:_____._kHz
RX:_____._kHz
SEL
OK
Cancel
******** Set up ********
------
Address ID ------
******** Set up ********
-------
Group ID -------
<add>
SEL
OK
Ç
Cancel
******** Set up ********
--------
Select --------
Address
ID
Group
ID
Call
frqeuency
Traffic
frqeuency
Scan
frqeuency
MMSI
check
SEL
OK
Ç
