D Technical Data
D.1 Scanner Specifications
Optical System
Maximum document width 25 x 17.7 inches / 635 x 450 mm
Resolution 1200 dpi
Sensor type Two tricolor CCDs, encapsulated and dust-
proof
12 bit grayscale (internal resolution)
36 bit color (internal resolution)
Sensor resolution 45,000 pixels (2x 22,500)
Scan modes 24 bit color, 8 bit indexed color
8 bit gray scale
1 bit Black/White
Scan accuracy ± 0,1%
Illumination
Light source Two lamps with white LEDs
Warm-up time None. Maximum brightness
switch-on.
Temperature dependence None
UV / IR emission None
Lifetime 50,000 hours scanning time
Glass plate
Mechanical load (maximum) 10 kg
Important: Do not exceed the maximum load!
D.2 Ambient Conditions
Operating temperature +5 to +40 °C / +40 to +105 °F
Storage temperature 0 to +60 °C / +32 to +140 °F
Relative humidity 20 to 80% (non-condensing)
Noise level 48 - 53 dB(A) (Operating)
33 dB(A) (Stand-by)
