True Scale Fabric Switches 12000 Series Hardware
July 2015 Installation Guide
Order Number: G91928004US 69
12000 Series Switches
Appendix A Intel 12000 Series Product Specifications
A.1 Physical Specifications
All products within the 12200, 12300 and 12800 Director series are designed to be
installed in industry-standard 19-inch four-post server racks.
Racks should conform to conventional standards. Use the American National Standards
Institute (ANSI)/Electronic Industries Association (EIA) standard ANSI/EIA-310-D-92
and International Electrotechnical Commission (IEC) 297. These racks are
commercially available in various depths. It is recommended to use rack with minimum
of 36" depth to facilitate cable installation and routing. Other physical attributes are
shown in the table below.
Note: The 12000-series products should not be installed in two-post telecommunication
racks.
A.2 Environmental Specifications
• Operating temperature:
— 5°–40°C at sea level, altitude derating 1°C per 300m to 2,400m.
• Non-operating temperature:
— -40°C to 65°C
• Relative humidity (non-condensing):
— Operating 5%–85%; Non-operating 5%–90%
A.3 12200 and 12300
A.3.1 Cooling and Thermal Management:
• Cooling:
— Air cooled with a hot plug fan/power tray, three fans per tray, 40mm, 12VDC
(12300)
— Four fans, no fan trays (12200)
— Front-to-back airflow
Note: The 12200 also offers a reversed airflow model.
Table 3. 12000 Physical Attributes
Model # 12200 12300 12800-040 12800-120 12800-180 12800-360
Height (rack
units/inches)
1U/1.75" 1U/1.75" 5U/8.75” 10U/17.5" 14U/24.5" 29U/50.7”
Depth (without
cables)
24” 25 3/4" (654mm)
Width 17.32" (440mm)
Max weight (lb./
kg.)
15/6.8 26/11.8 100/45.5 155/70.5 285/129.3 536/243.1
