Intellian V100 User Manual

11
INTRODUCTION
Intellian v100 Features
Balance-free installation
The v100 is equipped with an integrated RF module consisting of BUC and LNB. This BUC
and LNB mounting assembly is attached to the rear side of the reector in order to support
easy conversion and balance-free installation.
Optimized reector for Ku or Ka-band
The v100 is designed and engineered to operate on both Ku and Ka-band. The reector of
the v100 is capable of handling either Ku or Ka-band without the need to replace the reector
when the system is converted to Ka-band. The system is supplied with a Ku-band feed chain
as standard. The 1m reector for the v100 satises EIRP and G/T performance of both Ku
and Ka-band.
Gyro-free satellite search capability
Intellian’s new generation gyro-free satellite search function enables the v100 to acquire and
lock onto the satellite without requiring a separate input from the ship’s gyrocompass.
DVB/DVB-S2 and NBD detection capability
Intellian v100 is capable of detecting DVB-S/DVB-S2 signal, SCPC, and Narrow- Band signal
using integrated digital tuner and the narrow band detector (NBD).
Graphical and user-friendly antenna control software
Intellian’s next generation Antenna Control Software, ‘Aptus
®
’ is developed based on the
Intellian developed ‘Antenna Remote Management System (ARMS) Software Development
Kit (SDK)’. This graphic-based software is designed to remotely monitor and control Intellian
antennas through an IP network.
Dedicated Management Ethernet Port
The v100 has a Management Ethernet Port on the ACU front that enables direct and simple
network connection between a PC and the ACU. The Management Port supports DHCP
network connection by default, allowing automatic IP congurations, Internet access and
quick access to Intellian's remote management solution, the Aptus Web.
Wireless access via Wi-Fi
The built-in Wi-Fi wireless network card enables the ACU to be wirelessly connected that can
be either turned on and off by a switch. Any kind of wireless devices such as PCs, laptops
and smartphones can be used to connect to the ACU and monitor, control and change the
settings of Intellian antenna system wirelessly.
Intelligent rmware upgrade
Intellian v100 provides easy and intelligent rmware upgrade methods. Firmware upgrade
can be automatically initiated by plugging a rmware stored USB Memory Stick to the USB
Port on the ACU front or by launching ‘Firmware Upgrade’ on the Aptus
®
or Aptus Web.
User can also manually select a rmware le on a local disk and complete the upgrade. The
rmware can be rolled back to a previous version as the ACU’s built-in memory stores the
current and previous rmware les.

Intellian V100 Specifications

General

Frequency Band	Ku-band
Polarization	Linear
Reflector Material	Aluminum
Stabilization	3-axis
Antenna Diameter	1.0 m
Operational Temperature	-30°C to +55°C
Wind Survival	100 knots
Type	VSAT Antenna

Summary

INSTALLING THE ANTENNA

Planning the Installation

Antenna Installation

Step-by-step instructions for unpacking and installing the antenna unit.

INSTALLING THE ACU

Mounting the ACU

Methods for mounting the ACU, including rack and table types.

Gyrocompass Connection

PC to ACU Communication Setup

Establishes data communication between a PC and the ACU via TCP/IP.

Wi-Fi Connection

OPERATING THE ACU

Normal Mode

Setup Mode

How to enter and exit the system's setup mode for configuration.

Installation Settings

Guides initial setup of satellite, location, and gyro type.

Manual Search

Steps to manually search and peak the satellite signal.

Setup Antenna LNB pol Angle

Search Parameters

Antenna Diagnostic Test

Executes diagnostic tests to identify system issues.

Satellite Settings

Loading, editing, and adding satellite information for tracking.

Load Satellite

Selects and loads a satellite for tracking.

Edit Satellite Information

System Settings

Configures LNB frequency, location, modem, and management options.

Set LNB Local Oscillator Frequency

Set Location

Set Modem Port

Selects modem type, port, and protocol for satellite communication.

Aptus®

Introduction to Aptus®

Software Installation

Steps to install the Aptus software on a computer.

PC to ACU Communication Setup

Establishes data communication between PC and ACU via Aptus.

System Property Status Dashboard

Monitors antenna status, signal, GPS, and software information.

Work View Tabs

Satellite

Monitor

Diagnostic / Modem

Performs diagnostic tests and configures modem interface.

Aptus® WEB

Introduction

Remote monitoring and control of v-Series via TCP/IP using Aptus Web.

Main Page

Login page for Aptus Web, allowing control or monitoring modes.

Top Menus

Dash Board & Information

Quick monitoring of antenna status and settings via dashboard.

Antenna Settings

Configures ship info, GPS, block zones, and tracking parameters.

Ship Setting

Antenna Position & Parameters

Adjusts antenna position, sensor bias, and search parameters.

Tracking Setting

Sets tracking mode, frequency, and satellite parameters.

Modem Setting

Configures modem interface, port, protocol, and parameters.

Library Setting

Firmware & Configuration

Upgrades antenna and ACU firmware versions.

Antenna Firmware Upgrade

Steps for upgrading antenna and ACU firmware.

Administration

Configures network, SNMP, user management, and device settings.

Network Setting

iARM Upgrade

Technical Specification

Antenna system performance (V3-11X-XXX)

Technical performance metrics like frequency, gain, and G/T.

Rack Mount Antenna Control Unit (VP-TXXX)
