Intellian V100 User Manual

v100 – Marine Satellite Communication System
114
Introduction
With embedded Remote Access (Aptus Web) function, the v-Series can be
monitored, controlled, and diagnosed remotely from anywhere, anytime through
the TCP/IP protocol. This not only can save time but also save the cost generated
from the hundreds of routine maintenance activities such as operating rmware
upgrades, tracking parameters resets, and system diagnostic.
How to access Aptus Web:
1. Connect an Ethernet Cable between your PC and the Management Ethernet Port.
2. Enter the ACU's IP address (192.168.2.1) into your web browser's address bar to
login into the ACU’s internal HTML page, if this system has not been changed from
the ACU’s factory default.
NOTE: Aptus Web can be displayed in Internet Explorer 7 or later and is also compatible
with Firefox and Chrome web browser.

Intellian V100 Specifications

General

Brand	Intellian
Model	V100
Category	Antenna
Language	English
