158
Technical Specication
General
Approvals
CE – conforms to EU Directive 89/336/EEC
FCC – veried to CFR47: Part 15
Dimensions
Satellite antenna unit 138cm x 151.4cm (54.33" x 59.63")
Antenna dish diameter 103cm (41”)
Antenna control unit 43.1cm x 38cm x 4.4cm (17” x 15” x 1.7”)
Weight
Satellite antenna unit
Radome: 35.4kg
Antenna: 92kg
Antenna control unit 3.5 kg (7.7 lbs)
Antenna system performance (V3-11X-XXX)
Tx Frequency 13.75~ 14.5 GHz Ku-band
Tx Gain 41.6 dBi @ 14.25 GHz
Rx Frequency 10.7 ~ 12.75 GHz Ku-band
Rx Gain 39.4 dBi @ 11.7 GHz
Polarized Feed Cross-pol and Co-pol
Cross-pol Isolation Minimum 35 dB
G/T > 19.6 dB/k (@ 12.5 GHz)
Azimuth Range Unlimited
Elevation Range -20° ~ +115°
Cross-level Range ±37°
Stabilization Accuracy 0.2° peak mis-pointing @ max ship motion condition
Max Ship’s motion ±25°roll, ±15° pitch, ±8°yaw@ 6 sec
Turning rate Up to 10°/ sec 2
BUC 4W, 8W, 16W (optional)
Power Consumption 100 ~ 240 V AC, 50 ~ 60Hz, 3A
Rack Mount Antenna Control Unit (VP-TXXX)
Display 2 Line 40 Character Graphic VFD Module
PC Interface RS232C (57600 bps 8, N, 1) / USB
Modem Interface Ethernet port / RS232C / I/O ports
RF Interface Antenna RX: N-Type, Modem RX: F-Type
Gyrocompass Interface NMEA 2000 / NMEA 0183
GPS Interface NMEA In / NMEA Out
Remote Access RJ45, TCP / IP
Power Consumption 100 ~ 240 V AC, 50 ~ 60Hz, 1A
