v100 – Marine Satellite Communication System
154
Integrated with Hughes HX200
• Hughes Modem interface through the Console Connector
Antenna Rx
HX200
Antenna Control Unit
Internet / Email
DSUB
9 PIN
MALE
GND 1
GPS 6
GPS+ 2
RX LOCK 3
TX MUTE 4
3 GND
DSUB
15 PIN
FEMALE
3 rows
12 GPS
15
RX
LOCK
9 TX MUTE
ACU Console Modem Serial Port
