1. The data communication is being established between the antenna and the ACU.
INITIALIZE - ANTENNA INFO
INTELLIAN v 100
2. The ACU receives antenna information.
INITIALIZE - EL P OSITION
INTELLIAN v 100
3. The elevation angle and cross level angle are initialized.
INITIALIZE - AZIMUTH POSITION
INTELLIAN v 100
4. The azimuth angle is initialized.
INITIALIZE - SAT POSITION
INTELLIAN v 100
5. The antenna returns to the target satellite position.
SEARCH1 138.0E TELST_18 SIG:3 01 VL
AZ: 292.7( 202.7) EL: 48.3 SK: -72.0
6. The antenna is searching for the target satellite.
TRACKING 138.0E TELST _18 SIG:501 VL
AZ: 292.7( 202.7) EL: 48.3 SK: - 72.0 Fn
7. The antenna has locked onto the satellite.
Startup
With the system installed and power applied, the ACU screen will show the following
sequence.
Normal Mode
Start up
Initialize antenna info
Initialize elevation &
cross level angle
Initialize azimuth angle
Initialize target satellite
position
Search status
Tracking status
