Installation Settings
During the rst time installation, it is required to setup the installation settings.
Installation
menu
Latitude & Longitude
Gyro type
Select satellite
Setup mode
SETUP MODE ?
YES NO
1. Touch LEFT arrow key to move cursor to YES and touch OK key to enter SETUP mode
+ANTENNA +SATELLIT E
+SYSTEM
+INSTALLATION
2. Touch arrow keys to move cursor to INSTALLATION menu and touch OK key to enter it.
SELECT SATELLITE
[1] TELST_ 18 138.00E
3. Touch UP and DOWN arrow keys to select the satellite that you wish to track and touch
OK key to load the selected satellite.
LAT ITUDE LONGITUDE
37.00N 126.53E
4. Set the current LATITUDE and LONGITUDE
Touch LEFT and RIGHT arrow keys until the desired character is underscored (selected).
Touch UP and DOWN arrow keys to increase or decrease the value. Or touch NUMBER keys
to set the desired value directly. Touch OK key to set the parameter.
GYRO TYPE BOW OFFSET
NMEA 000
5. Set the ship’s GYRO TYPE* & BOW OFFSET
A search pattern 1 or 3 will be initiated according to which gyrocompass type is selected and
the existence of the gyrocompass input. Ensure that the supported gyrocompass type is set
correctly. If the ship's gyrocompass output is different than NMEA, A search pattern 1 will
be initiated automatically if the gyrocompass input does not exist and the gyrocompass type
that is selected is different than GROUND TEST.
The BOW OFFSET is to offset the angle difference between the antenna’s bow and the ship’s
bow (Range: 0 – 360°).
NOTE: The bow offset will not be saved automatically if Search 1 pattern is initiated. In this case, the
antenna will need to retarget the desired satellite using Search 1 every time if the antenna restarts.
