Setup Antenna LNB pol Angle
LNB pol angle type
Setup mode
Set pol angle menu
Antenna menu
LNB pol angle Signal
Mechanical Skew Offset
SETUP MODE ?
YES NO
1. Touch LEFT arrow key to move cursor to YES and touch OK key to enter SETUP mode.
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Touch OK key to enter ANTENNA menu.
+MANUAL SEARCH +SET POL ANGLE
+SEARCH PARAM +SET PAR AMETERS
3. Touch RIGHT arrow key to move cursor to SET POL ANGLE menu and touch OK key to
enter it.
SELECT LNB POL. ANGLE ME NU
CALIBRATION
4. Touch UP and DOWN arrow keys to select the LNB pol angle menu and touch OK key to
run the selected operation 'CALIBRATION', 'MANUAL ADJUST' or 'RESET MECHANICAL
OFFSET'. Select MANUAL ADJUST to control LNB pol angle manually. If the control board,
LNB pol potentiometer or belt is replaced, select CALIBRATION to calibrate LNB pol angle.
If the satellite skew offset is unknown, you may select RESET MECHANCAL OFFSET to reset
the mechanical skew offset (Overall system skew offset = satellite skew offset + mechanical
skew offset).
LNB POL A NGLE SIGNAL: 180
20
5. Touch UP and DOWN arrow keys to increase or decrease the LNB pol angle manually and
the correspondent SIGNAL level will be displayed next to it. Touch BACK key to return to the
main display.
NOTE: LNB POL ANGLE menu will be displayed only if MANUAL ADJUST is selected.
SELECT LNB POL.ANGLE MENU
RESET MECHANICA L OFFSET
6. Press OK keys to reset the mechanical skew offset.
