50
4. Touch RIGHT arrow key to display NBD, GPS and ship’s heading information.
5. NBD, GPS and ship’s heading information are shown.
- NBD (Narrow Band Detection) IF tracking frequency: 1247000 kHz
- Detected Band Width: 1000 kHz
- SIG/dB scale (Signal Level ): 140/14.0dB (When NBD mode for tracking signal is chosen)
- W (West)/E (East) Longitude: 4.53º E
- N (North)/S (South) Latitude: 52.22º N
- HDG (Ship’s Heading): 90º
- LNB local oscillator (LO) frequency: 10000 MHz
V3-11B-PJW ANT SERIAL 1.00(1.00)
VP-T537 ACU SERIAL 1.00
7. Touch RIGHT arrow key to display the below information.
- Antenna part number, antenna serial number and PCU and Stabilizer rmware version.
- ACU part number, ACU serial number, ACU rmware version and Library version.
Touch BACK Key to return to the rst page of the antenna current status.
Tracking & Heading
information
Antenna & ACU
versions
TRACKING 138.0E TELST_18 SIG:301 VL
AZ: 292.7( 202.7) EL: 48.3 SK: -72.0 Fn
NBD F:1247000 BW:1000 SIG:3 01
004 .53E 52.22N HDG:090.0 L:10000 Fn
Current tracking status
8.Touch RIGHT arrow key to display the USB FUNCTION*
This menu will be displayed automatically if a USB ash drive is plugged into the USB port
located in the front panel of the ACU.
USB FUNCTION*
• UPGRADE FIRMWARE: upgrade the system by using the rmware les
(les format: *.FWP) from the specied folder in the USB ash drive.
• COPY LOG DATA: Copy the up-to-date log data from the system to the USB ash drive.
Select
USB
functions
[USB FUNCTI ON] SELECT USB FUNCTION
UPGRADE FIRMWARE
