v100 – Marine Satellite Communication System
152
Antenna Rx
Internet / Email
Modem Interface
PC Interface
Integrated with Comtech
• Comtech Modem interface through the Console Port
Antenna Control Unit
Comtech CDM-570/L
DSUB
9 PIN
MALE
GND 1
GPS 6
GPS+ 2
RX LOCK 3
TX MUTE 4
1 GND
DSUB
15 PIN
FEMALE
2 rows
7
RX
Comm
15
Modem
LOCK
9 TX MUTE
ACU Console Modem Console Port
