APPENDIX

PC Interface

Antenna Control Unit

Integrated with Gilat SkyEdge

• Gilat Modem interface through Serial Port

Gilat SkyEdge Modem

(96000 bps.)

9 PIN

FEMALE

GND

RJ-45RX

GND

ACU Serial Port Gilat SkyEdge

RS 232

DB-9 Female

Serial Port

RJ-45
