INVT Goodrive200A Series User Manual

GD200A series VFD Product overview
-8-
3. The 037G/045P and higher models can be installed with optional braking units and the braking
unit and resistor are optional.
3.3 Product specifications
Function
Specification
Input
Input voltage (V)
AC 3PH 380V(-15%)–440V(+10%)
Input current (A)
See Rated specifications.
Input frequency (Hz)
50Hz or 60Hz
Allowed range: 47–63Hz
Output
Output voltage (V)
0–Input voltage
Output current (A)
See Rated specifications.
Output power (kW)
See Rated specifications.
Output frequency (Hz)
0–400Hz
Technical
control
feature
Control mode
SVPWM, SVC
Motor type
Asynchronous motor
Speed ratio
Asynchronous motor 1: 100 (sensorless vector
control)
Speed control accuracy
±0.2% (sensorless vector control)
Speed fluctuation
± 0.3%(sensorless vector control)
Torque response
<20ms(sensorless vector control)
Torque control accuracy
10%(sensorless vector control)
Starting torque
Asynchronous motor: 0.5Hz/150% (SVC)
Overload capability
G type:
150% of rated current: 1 minute
180% of rated current: 10 seconds
200% of rated current: 1 second
P type:
120% of rated current: 1 minute
180% of rated current: 10 seconds
180% of rated current: 1 second
Running
control
feature
Frequency setting
Digital setting, analog setting, pulse frequency
setting, multi-step speed running setting, simple PLC
setting, PID setting, MODBUS communication
setting.
Shift between the set combination and set channel.
Auto voltage adjustment
Keep a stable voltage automatically when the grid
voltage transients
Fault protection
Provide over 30 fault protection functions:
overcurrent, overvoltage, undervoltage, overheating,
phase loss and overload, etc.
Speed tracking
Restart the rotating motor smoothly
Note: This function is available for the 004G/5R5P
and higher models.
