INVT Goodrive200A Series User Manual

GD200A series VFD Function parameters
-63-
Function
code
Name
Description
Default
value
Modify
P05.48
AI3 input filter
time
Setting range of P05.39: P05.37–10.00V
Setting range of P05.40: -100.0%–100.0%
Setting range of P05.41: 0.000s–10.000s
Setting range of P05.42: -10.00V–P05.44
Setting range of P05.43: -100.0%–100.0%
Setting range of P05.44: P05.42–P05.46
Setting range of P05.45: -100.0%–100.0%
Setting range of P05.46: P05.44–10.00V
Setting range of P05.47: -100.0%–100.0%
Setting range of P05.48: 0.000s–10.000s
0.100s
○
P05.50
Lower limit
frequency of
HDI
0.000kHz–P05.52
0.000
kHz
○
P05.51
Corresponding
setting of HDI
low frequency
setting
-100.0%–100.0%
0.0%
○
P05.52
Upper limit
frequency of
HDI
P05.50–50.00kHz
50.00
kHz
○
P05.53
Corresponding
setting of upper
limit frequency
of HDI
-100.0%–100.0%
100.0%
○
P05.54
HDI frequency
input filter time
0.000s–10.000s
0.100s
○
P06 Group Output terminals
Function
code
Name
Description
Default
value
Modify
P06.00
HDO output
The function selection of the high-speed pulse
output terminals.
0: Open collector pole high speed pulse output:
The max. pulse frequency is 50.0kHz. See
P06.27–P06.31 for detailed information of the
related functions.
1: Open collector pole output. See P06.02 for
detailed information of the related functions.
0
◎
