User Manual QUILT MAKER PRO 20
To use rulers and templates with your quilng machine
U CAUTION: Use only 1/4 inch thick rulers with your machine. Do not use rotary-cutting rulers;
they are too thin and can easily slip under the hopping foot. Always use the Ruler Base to
stabilize the ruler.
Keep the ruler at and quilt only where the ruler is held securely. Avoid losing control by walking your hand
along the ruler or stopping and reposioning your hand and/or the ruler.
• Quilng with rulers requires gentle three-point pressure as follows:
1. Posion and press the ruler against any side of the hopping foot.
2. Press machine against ruler.
3. Press ruler against ruler base with only as much force as is necessary to keep the ruler from
slipping. Too much pressure will keep the machine from moving.
The quilng line will be approximately 1/4 inch away from the ruler edge. The markings on all Janome
rulers take this into consideraon.
 NOTE: Set the machine to stop in the needle-down posion to keep the machine from moving while
making adjustments with the ruler.
Rear Laser Stylus
The laser light (for use with pantographs) is installed on a mounng post. The post is threaded into a hole
on the machine casng. The hole is found towards the back of the machine on the free arm about 3 inches
in front of the rear wheel.
To install the mounng post and laser stylus
1. Locate the mounng post with nut and washer, the laser stylus, and the 8mm combo wrench.
2. Remove the nut and washer from the mounng
post. Place the nut all the way onto the
mounng post and then the washer (to protect
the machine paint). Thread the post into the
tapped hole on the machine all the way and
then x its posion by ghtening the nut.
