– 37 –

 4-10. Simpliedfunctionsetting

3 1

642

5 7

Function setting items can be simplied in part.

1) Keeping thread trimming prohibiting switch

held pressed, turn the power ON. Then, the

screen is changed over to the simplied func-

tion setting screen. The details displayed on

the screen represent the current settings.

2) Function items can be changed by pressing

switches

and

[Simpliedfunctionsettingscreen]

WARNING :

If the solenoid is used under the air drive mode, the solenoid can burn out. Be sure to carefully avoid

thewrongsettingofthepresserfootliftingdevicespecication.

■

Wiper function (WiP): Switches

and

This function activates the wiper.

oFF : The wiper does not operate after thread trimming.: The wiper does not operate after thread trimming.The wiper does not operate after thread trimming.

on : The w: The wThe wiper operates after thread trimming (standard setting at the time of delivery)

■

Auto-lifter (FL): Switches

and

This function activates the auto-lifter function when the presser foot lifting device (AK) is installed on the

sewing machine.

For the presser foot lifting device specications, solenoid drive mode (+33 V) or air drive mode (+24 V)

can be selected.

The drive source voltage (CN37) is changed over between +33 V and + 24 V according to the drive

mode specication selection.

oFF : Auto-lifter does not operate. (standard setting at the time of delivery): Auto-lifter does not operate. (standard setting at the time of delivery) Auto-lifter does not operate. (standard setting at the time of delivery)

(The presser foot does not automatically go up when the program sewing is completed.)

on S : Auto-lifter operates. (Solenoid drive mode [+33 V]): Auto-lifter operates. (Solenoid drive mode [+33 V]) Auto-lifter operates. (Solenoid drive mode [+33 V])

on A : Auto-lifter operates. (Air drive mode [+24 V]): Auto-lifter operates. (Air drive mode [+24 V]) Auto-lifter operates. (Air drive mode [+24 V])

■

Needle position changeover function for the time when the sewing machine stops (nP) :

Switches

and

The needle position at the time when the sewing machine stops can be changed over.

Lo : Lower stop position (standard setting at the time of delivery): Lower stop position (standard setting at the time of delivery) Lower stop position (standard setting at the time of delivery)

UP : Upper stop position: Upper stop position Upper stop position

3) Once you have completed the setting, press switch

. The screen is changed over to the power switch

OFF notication screen.

[PowerswitchOFFnoticationscreen]

4) Turn OFF the power switch to exit from the

simplied function setting.

If "on" (auto-lifter operates) is selected without the auto-lifter installed, the machine startup is

momentarily delayed at the beginning of sewing. In addition, the one-touch type reverse feed

(touch-back) switch may be disabled. To avoid these troubles, be sure to select "oFF" (auto-lifter

does not operate) when the auto-lifter device is not installed.
