JUKI IT-100 User Manual

– 41 –
* Do not change the set values with asterisk (
*
) mark as they are functions for maintenance. If the standard set value set at the
time of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
If it is necessary to change the set value, please purchase the Engineer’s Manual and follow the instructions.
Function setting list
No. Item Description Setting range Indication of function setting
1 Soft start function The number of stitches to be sewn at a low speed when the soft-
start function is used at the start of sewing.
0 : The function is not selected.
1 to 9 : The number of stitches to be sewn under the soft-start
mode.
0 to 9
(Stitches)
N-SOFT
2 Material end sensor
function
This item is not used on the IT-100.
0/1
ED
3 Thread trimming
function by material
end sensor
This item is not used on the IT-100.
0/1
EDTRM
4 Number of stitches
for material end
sensor
This item is not used on the IT-100.
0 to 19
(Stitches)
EDN
5 Flicker reducing
function
Flicker reducing function
0 : Flicker reducing function is not operative.
1 : Flicker reducing function is effective
0/1
T-ACC
6 Bobbin thread
counting function
Bobbin thread counting function
0 : Bobbin thread counting function is not operative.
1 : Bobbin thread counting function is operative.
0/1
SCBOB
*
7 Unit of bobbin
thread counting
down
Unit of bobbin thread counting down
0 : 1 Count/10 stitches
1 : 1 Count/15 stitches
2 : 1 Count/20 stitches
3 : 1 Count/thread trimming
0 to 3
RATIO
*
8 Sewing speed
of reverse feed
stitching
Sewing speed of reverse feed stitching
150 to 3,000
(sti/min)
S-BT
9 Thread trimming
prohibiting function
This item is not used on the IT-100.
0/1
TRMINH
10 Setting of needle
bar stop position
when the sewing
machine stops.
Position of needle bar is specied when the sewing machine stops.
0: The needle bar stops at its lower position.
1: The needle bar stops at its upper position.
0/1
NPS
11 Operation
conrmation sound
for operation panel
Operation conrmation sound for operation panel
0 : Operation conrmation sound is not generated
1 : Operation conrmation sound is generated.
0/1
SOUND
12 Optinal switch
function selection
Switching of function of optional switch.
*
13 Function of
prohibiting start
of the sewing
machine by bobbin
thread counter
Function of prohibiting start of the sewing machine by bobbin thread counting
0 : When counting is out (-1 or less) Function of prohibiting start
of the sewing machine is not operative.
1 : When counting is out (-1 or less) Function of prohibiting start
of the sewing machine after thread trimming is operative.
2 : When counting is out (-1 or less), the sewing machine stops
once. Function of prohibiting start of the sewing machine after
thread trimming is operative.
0 to 2
ASCNT
14 Sewing counter Counting function of sewing (number of completion of process)
0 : Sewing counter function is not operative.
1 : Sewing counter function is operative. (Every time thread trim-
ming is performed)
2 : With the sewing counting switch input function
0 to 2
NTO
15 Thread wiping
function after
thread trimming
Thread wiping operation after thread trimming is specied.
0 : Thread wiping is not carried out after thread trimming
1 : Thread wiping is carried out after thread trimming
0/1
N-WIPER
21 Function of
automatic presser
foot lifting at pedal's
neutral position
Function of lifting presser foot when the pedal is in neutral position.
0 : Function of neutral automatic presser lifting is not operative.
1 : Selection of function of neutral presser lifting.
0/1
N-NPL
22 Needle up/down
correction switch
changeover
function
Function of the needle up/down correction switch is changed over.
0 : Needle up/down compensation
1 : One stitch compensation
0/1
F-CMSP
25 Thread trimming
operation after
turning the
handwheel by han
Thread trimming operation after moving the needle away from its up-
per or lower position by turning the handwheel by hand is specied.
0 : Thread trimming operation is carried out after turning the
handwheel by hand
1 : Thread trimming operation is not carried out after turning the
handwheel by hand
0/1
F-TRMC
29 Setting of one-
touch type reverse
feed solenoid pull-
in time
This function sets the suction time of initial motion of back-tack sole-
noid.
50 ms to 500 ms
50 to 500
(ms)
T-RSS
30 Function of reverse
feed stitching on
the way
Function of reverse feed stitching on the way
0 : Normal one-touch type reverse feed stitching function
1 : Function of reverse feed stitching on the way is operative.
0/1
OBT
