– 61 –
(3) Uploading/downloading the sewing recorder data
E. End switch
The popup screen is closed to restore
the screen to the previous one.
D. Upload/download start switch
After having made selections with
switches A, B and C, start uploading or
downloading.
A. Data No. 1/No. 2 selector switch
Production volume
count-up switch
1
B. Upload/download selector switch
Data No. 1/No. 2 selector popup screen appears. Select either the
data No. 1 or the data No. 2.
The upload/download selector popup screen appears.
Select either uploading from the sewing machine into a
medium or downloading from a medium into the sewing
machine.
C. File No. selector switch
The le No. selector popup screen appears. Select a le
number of uploaded les on a medium using the Numeric
switches 0 to 9 and + and - switches.
<Sewing recorder communication screen>
When the "data upload/download switch" (switch
7
described on the previous page) is pressed, the sewing
recorder communication screen is displayed as shown below.
On this screen, the data can be downloaded from a medium into the sewing machine and can be uploaded
from the sewing machine into a medium.
* File of the selected number stored in a
medium can be deleted.
Upload from the sewing machine into a medium
Download from a medium into the sewing machine
To Next Page
