MS-1190, 1260, 1261 (September, 2003) 1/5
Model name
Application
No. of needle
Max. sewing speed
Needle bar stroke
Needle
(at the time of delivery)
Needle gauge
Stitch length
Lift of the presser
foot
Thread take-up lever
Circumference of
tube at the needle
entry
Needle guard
Stitch adjusting
system
Lubrication
Lubricating oil
MS-1190 MS-1190M MS1260/V045 MS-1261M/V045 MS-1261/V045
MS-1190/V046 MS-1190M/V045 MS-1260 MS-1261M MS-1261
For light-weight For medium-weight For extra heavy-weight
materials materials
For medium-to heavy-weight materials
materials for jeans
23
4,000rpm (normal 3,500rpm) 3,600rpm (normal 3,000rpm)
28.0mm 33.2mm
SCHMETZ B-64 (Nm80) SCHMETZ B-64 (Nm100) SCHMETZ UY128GAS (Nm120) SCHMETZ UY128GAS (Nm130)
Nm60
〜
Nm90 Nm80
〜
Nm120 Nm100
〜
Nm140 Nm100
〜
Nm140
ORGAN TV
×
64-NY (#12) ORGAN TV
×
64-NY (#16) ORGAN UY
×
128GAS-NY (#19) ORGAN UY
×
128GAS-NY (#21)
#8
〜
#14 #12
〜
#19 #16
〜
#22 #16
〜
#22
3.2mm (1/8"), 4.0mm (5/32"), 4.8mm (3/16"),
4.8mm (3/16")
5.6mm (7/32"), 6.4mm (1/4"), 7.2mm (9/32"),
5.6mm (7/32"), 6.4mm (1/4") 8.0mm (5/16"), 9.6mm (3/8")
1.2
〜
3.2mm 1.4
〜
4.2mm
10mm
Thread pulling cam type
Needle bar thread take-up lever
thread take-up lever
171mm 190mm
Longitudinally-fixed needle guard Backward travelling needle guard
By push-button (with locking mechanism)
Semi-automatic lubrication
JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
● Both needle thread tension and bobbin thread tension have been decreased
after reinvestigation of the double chainstitching mechanism. Furthermore,
the stitch dial, gauges and looper have been dramatically improved, thereby
forming beautifully finished seams and preventing puckering.
● Relation between the needle and the looper, and the relation between the
needle and the feed have been changed. This enables the machine to
consistently form seams of uniform quality. The machine prevents stitch
skipping when it runs at high speed, thereby producing higher-grade
products.
● Newly developed folders are equipped as standard for the machine.
The folders are designed to match the presser foot and allow overlapping
material to be fed smoothly under them. They are easy to use and improve
consistency in sewing. Many different kinds of folders are prepared in
accordance with the materials, ranging from extra heavy-weight materials to
medium-weight materials.
MS-1190
● The placement of the feed mechanism has been charged to decrease the
feed amount when the needle enters the material, thus preventing the
needle from bending. The bobbin thread is clamped without fail, thereby
producing consistent thread loops. The looper tucks the needle thread
without fail, thereby finishing uniform seams.
● The number of teeth of the feed dog has been increased so that it can
easily catche overlapping material. The shape of the presser foot has been
modified to prevent single-sided contact with the overlapped part.
The movable needle guard (rear) is provided with a vertical adjusting
mechanism. These features contribute to smoother feed of heavy-weight
materials, thereby preventing stitch skipping.
● Thanks to the tread guide located between the needle bar thread take-up
and the intermediate tension release lever, the timing to tense the needle
thread can be changed and the bobbin thread tension can be decreased.
As a result, the machine is capable of beautiful finished stitches with a soft
appearance even when heavy-weight material is used.
MS-1261/V045
SPECIFICATIONS
MS-1190
Feed-off-the-arm, 2-needle Double Chainstitch Machine
MS-1260
(2-needle)
MS-1261
(3-needle)
Feed-off-the-arm, 2-needle/3-needle Double Chainstitch Machine
