ML-111 (September, 2003) 1/1
ML-111
SPECIFICATIONS
APPLICATIONS
● The basting of the front edges, edge and stand of collars, flaps of men's and ladies' suits and coats.
● The basting of the waist bands, the flies of trousers slacks, etc.
● High efficient basting works at a sewing speed of 1,800rpm.
● Chainstitch is continuously formed with a single thread and by
a blind looper which eliminates the need for a bobbin thread
refilling. In addition, the basted seam can be easily undone.
● Basting works are efficiently done with a maximum stitch length
of 10mm which is easily set up by a control dial.
ML-111
Single-thread, Chainstitch Basting Machine
Model name
Max. sewing speed
Max. stitch length
Needle bar stroke
Lift of the presser foot
Needle (at the time of delivery)
Thread take-up
Feed dog
Looper
Lubrication
Lubricating oil
Distance from needle to machine arm
Size of bed
Weight of the machine
ML-111
1,800rpm
10mm
35mm
By hand: 5.5mm, By knee: 12mm
TV×7 (#14) #11〜#14
Needle bar thread take up
3-row feed dog
Blind looper
By an oiler
JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
300mm
476mm×178mm
29kg
