V050 SERIES (September, 2003) 1/4
DDL-5550N-7/V052A
MS-1190/V054A
● The cloth puller effectively prevents sewing trouble, including irregular
stitches, puckering and stitch gathering. In addition, it controls the
straight stitching capability of the sewing machine.
● The feed amount can be easily regulated by the simple operation of a
dial. The dial has a clearly legible scale, allowing the operator to
perform adjustment without having to stand up.
● Because of its higher drawing force, the cloth puller can smoothly feed
overlapped portions of a material. It is also smoothly adaptable to
curved and leaned portions, thereby allowing the operator to handle
the material without difficulty.
● The cloth puller features an auto-lifter that interlocks with a knee-lifter
lever and reverse-stitching lever to raise the roller when performing
reverse stitching. It can also be used with the sewing machine with a
wiper.
V050 SERIES
Cloth Puller
● The roller is placed near the needle.
This means that the material can be easily
handled in the case of sharp curve stitching
and short-distance stitching.
● To avoid interference with the presser foot in
the case of reverse feed stitching, etc., the
roller comes with an automatic double-
stepped stroke lifter that lifts the roller to
certain height for turn-out, and then lifts it
again to the highest position of its stroke.
● Large feeding mechanism properly feeds the
material straight.
It is best-suited to medium-weight materials.
● For heavy-weight materials and long
materials, it is effective to use a roller liner
that securely holds the material in
combination with the V050 series.
(the roller liner is supplied as standard with
the large roller as an accessory. )
● This type of puller securely pulls the
material while placing it between the top
and bottom rollers. This means that the
puller achieves high-quality seams free from
puckering even when using newly-
developed materials.
● Strong pulling force ensures an upgraded
efficiency for the sewing of large materials
and long materials.
SPECIFICATIONS
V051 V052 V053
• Lockstitch machine........Intermittent feed that is almost
same as the continuous feed
• Chainstitch machine......Intermittent feed
One-way system interlocked with the feed mechanism
of the sewing machine
0〜6 mm＊
Proximity type Large roller type
Top and bottom
roller type
Manual 10mm 14mm 12mm
Auto 4mm 12mm 5.5mm
Approx. 13kg
Single-/3-phase
Feed method
Feed mechanism
Feed amount of roller
Lift of the roller
Weight
Power supply
＊The feeding length of puller varies a little with sewing speed.
Proximity type Large roller type Top and bottom rollers type
