MBH-180, 180S, 180L (September, 2003) 1/2
MBH-180
SPECIFICATIONS
3,300rpm
6.4〜34.9mm (1/4"〜1-3/8") ＊6.4〜22.2mm (1/4"〜7/8") 6.4×38.1mm (1/4"〜1-1/2")
1.6〜2.4mm
0.4〜1mm
27mm
7mm (normal: 5mm)
2mm
(when the presser foot is in its
most advanced position)
DB×1 (#14) #11〜#16 DB×1 (#14) #11〜#14 DB×1 (#14) #11〜#16
16×231 (Nm90) Nm75〜Nm100 16×231 (Nm90) Nm75〜Nm90 16×231 (Nm90) Nm75〜Nm100
By an oiler
JUKI New Defrix Oil No.2 (equivalent to ISO VG32)
470mm (W) ×212mm (L) ×260mm (H)
● The machine demonstrates its improved capabilities to speed up
the progress of work, it achieves a shorter cycle time and does
not require bobbin thread changing.
● Consistent feed pitch ensures beautifully-finished, high quality
seams.
● Sewing size and stitch length can be easily adjusted.
● The machine is provided with an auto-lifter and an automatic
thread trimmer controlled by the one-pedal unit. This means
that the operator can perform continuous operations with ease.
● For the MBH-180L, single-thread chainstitch and double
chainstitch settings can be quickly changed over.
● Labels can be attached to men's shirts, blouse, sport shirts.
MBH-180
(buttonholing type)
MBH-180S
(decorative buttonhole type)
MBH-180L
(label attaching type)
Single-thread, Chainstitch Machine
Model name
Application
Max. sewing speed
Sewing size
Overcasting width
Max. stitch length
Needle bar stroke
Max. lift of the presser foot
Needle (at the time of delivery)
Lubrication
Lubricating oil
Dimensions
MBH-180
Standard buttonholing
process for shirts
MBH-180S
Decorative buttonhole process
for men's upper garments
MBH-180L
Various label attaching
processes
＊The sewing size can be set to 38.1mm (1-1/2") at the maximum by changing the presser foot.
