LB-3, LB-4 (September, 2003) 1/1
Overlock Machine with Semi-automatic Backlatch Device
[1-needle]
M
O
-6□04S-0E6-300/LB-3
[2-needle]
M
O
-6□14S-BE4-307/LB-4
Variable Top-feed Overlock Machine
with Semi-automatic Backlatch Device
[1-needle]
M
O
-6904R-0E6-300/LB-3
[2-needle]
M
O
-6914R-BE4-307/LB-4
MO-6914S-BE4-307/LB-4
M
O
6 04S0E6300/LB3
Model Code
MO-6704S 7
MO-6904S 9
M
O
6 14SBE4307/LB4
Model Code
MO-6714S 7
MO-6914S 9
Auto-lifter
Compressed air
Provided as standard
0.5 MPa (5kgf/F)
● Aided by the precise control of the stitch number provided by the
material-edge sensor and SC-380 motor/controller, the tension-release
mechanism is activated during production of chain-off thread at both the
start and end of sewing so that thin chain-off thread can be produced.
The chain-off thread is completely tucked into the finished seam on the
material to achieve a beautifully finished sewing product.
● For the 2-needle overlock machine, the throat plate intermediate claw
automatically moves backward at the end of sewing so that the chain-off
thread can be guided to the needle thread retainer without getting
caught by the claw. At the start of the next sewing, the chain-off
thread is rolled into the stitches to the material edge, giving the seam a
beautiful finish.
● For both 1-needle and 2-needle overlock machines, the tension-release
function can be disabled by setting the material edge sensor in the OFF
state. In addition, for 2-needle machines, the intermediate claw of the
throat plate can be fixed with projected. This means that the machine
can be used as a standard machine with standard specifications for
processes not requiring the backlatching capability such as continuous
stitching and runstitching, thereby saving on new equipment.
SPECIFICATIONS
＊For specifications not listed above, refer to the respective model
catalogs.
WHEN YOU PLACE ORDERS
M
O
6904R0E6300/LB3
M
O
6914RBE4307/LB4
● Overlock Machine
● PSC box
(1-needle)
(2-needle)
● Variable Top-feed Overlock Machine
(1-needle)
(2-needle)
Throat plate
intermediate claw
backward
Throat plate
intermediate claw
backward
■
Throat plate intermediate claw forward/backward mechanism
(for 2-needle machines)
SC-510/M51
＊JUS: North America and Central and South America.
SC510 S
Control box Code
Standard S
PSC box Code
For JUS
＊
(LA) Single-phase 100〜120V PFL S
For JUS
＊
,
General Export 3-phase 200〜240V PFL D
For General Export Single-phase 200〜240V PFL K
For EU (CE) Single-phase 200〜240V PFL N
For JUS
＊
(LA) Single-phase 200〜240V PFL U
M51
● Motor for SC
