MB-373NS Series (September, 2003) 1/2
,,
● The 4-holed button sewing mode can be easily switched over to
the 2-holed button sewing mode in accordance with changing
sewing specifications. Furthermore, the button hole interval can
be easily changed by operating the lever.
● The number of stitches can be quickly selected from among 8,
16 and 32 stitches corresponding to the change in sewing
specifications.
● The machine ensures consistent sewing performance even when
it runs at 1,500rpm. The unique speed-decreasing device reduces
vibration when the sewing machine stops, thereby enabling the
sewing machine to beautifully finish buttons with accuracy.
SPECIFICATIONS
Model name MB-373NS
Thread trimming mechanism
Interlocked with the presser lifter
Cut with the fixed knife and moving knife
Sewing speed Max 1,500rpm, Normal 1,300rpm
Number of stitches 8, 16 and 32 stitches (6, 12 and 24 stitches are also available by changing the cam)
Feed length Crosswise feed 2.5〜6.5mm, Lengthwise feed 0〜6.5mm
Stitching shape
Applicable button
Round-shaped flat button (2-holed, 4-holed)
Shank button, Wrapped-around button, Snap, Label, Metal button, Stay button
(exclusive attachments have to be used)
Button size φ10〜φ28mm
Thickness of button Max. 5mm
Needle bar stroke 48.6mm
Needle (at the time of delivery) TQ×7 (#16) #14〜#20
Button clamp lifting system Automatic system (pedal type possible)
Sewing system Single thread chainstitch
Stop-motion mechanism
Automatic stop-motion mechanism
(equipped with the speed-decreasing device and the reverse rotation preventing device)
Lubrication By an oiler
Lubricating oil JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
Power requirement/motor used Single- or 3-phase/200W (1/4 HP), general-purpose motor
Single-thread, Chainstitch, Button Sewing Machine
MB-373NS Series
WHEN YOU PLACE ORDERS
MB373NS /
● Machine head
MB-373NS
For sewing flat buttons
Subclass models Code
8, 16 and 32 stitches
8, 16 and 32 stitches 10
8, 16 and 32 stitches 11
Button clamp unit Code
For flat button
(small)
S
For flat button
(medium)
M
To Next Page
