MO-6900C Series (September, 2003) 1/2
● The cylinder-bed is bestsuited to the runstitching and blind hemming
of tubular materials.
● Since the machine comes with a needle-thread take-up mechanism as
well as a looper thread take-up mechanism, to enable sewing with a
lower tension applied to the material, it achieves soft-feeling high-
quality seams.
● Since the machine is provided as standard with the bottom feed dog
inclination-adjusting mechanism and the external differential feed-
increasing mechanism, it can be easily adjusted to ideally match the
material being sewn. In addition, the machine is provided as
standard with a micro lifter feature that offers improved
responsiveness to materials, and provides the operator with
upgraded operability. The stitch length can be easily adjusted with
the push-button mounted on the front surface of the sewing
machine.
SPECIFICATIONS
SUBCLASS MACHINE LIST
Super-high-speed, Cylinder-bed, Overlock Machine
M
O
-6900C Series
MO-6914C
Seams Model No.
Materials
Number
of
needles
Number
of
threads
Needle
gauge
(mm)
Overedging
width (mm)
Number
of
feed dog
rows
Stitch
length
(mm)
Presser
lifting
amount
(mm)
Needle system
Max.
sewing
speed
(rpm)
Bottom
differential-
feed ratio
Remarks
MO-6904C-0D6-307 1 3 − 3.2 3 3.5 1:0.8〜1:2.3 7 DC×27 #11 8,000
MO-6904C-0E6-307 L〜M1 3 − 4.0 3 3.5 1:0.8〜1:2.3 7 DC×27 #11 8,000
MO-6904C-0F4-307 1 3 − 4.8 2 3.5 1:0.8〜1:2.3 7 DC×27 #14 8,000
■ 1-needle overlock
Upper looper extra
high throw type
MO-6914C-BD4-307 2 4 2.0 3.2 2 3.5 1:0.8〜1:2.3 6.5 DC×27 #11 8,000
MO-6914C-BD6-307 L〜M2 42.0 3.2 3 3.5 1:0.8〜1:2.3 6.5 DC×27 #11 8,000
MO-6914C-BE6-307 2 4 2.0 4.0 3 3.5 1:0.8〜1:2.3 6.5 DC×27 #11 8,000
■ 2-needle overlock
Upper looper extra
high throw type
Model name MO-6904C MO-6914C
Stitch type 1-needle overlock 2-needle overlock
Stitch style in the U.S.A. 504 514
Max. sewing speed 8,000rpm
Stitch length 0.8〜 3.5mm
Needle gauge (mm) − 2.0
Overedging width (mm) 3.2, 4.0, 4.8 3.2, 4.0
Differential feed ratio For gathering 1:2.3 (max. 1:4.5), For stretching 1:0.8
Needle bar stroke 24.5mm
Inclination angle of the needle 20°
Needle mechanism Needle bar method and upper/lower bushing
Needle DC×27
Max. lift of the presser foot 7mm (excluding some subclass model)
Max. presser foot pressure 63.7N (6.5kg)
Stitch adjusting method By push-button
Differential-feed adjusting method By lever
Weight of the machine head 24kg
Lubrication Automatic
Lubricating oil JUKI Machine Oil 18 (equivalent to ISO VG18)
Needle cooler Provided as standard
Needle thread heat remover Provided as standard
Micro-lifter Provided as standard
