PLC-1610, 1610-7 (September, 2003) 1/2
PLC-1610-7-0B/XC-E500
SPECIFICATIONS
● The post-shaped bed minimizes bed's diameter, thereby providing easy
operation for three-dimensional sewing.
● Equipped with a unison-feed system that perfectly synchronizes the
presser foot, feed dog and needle, the machine feeds large-sized
materials smoothly and forcefully. This results in consistent sewing
performance at high speeds without irregular feed.
● The presser foot rises up to 15mm. This allows the operator to
place/remove heavy materials such as urethane on/from the machine
with ease. The machine is equipped as standard with a pneumatic
auto-lifter.
● The vertical stroke (alternating vertical movement) of the presser foot
and walking foot can be adjusted to 8mm at the maximum to
accommodate the thickness of multi-layered portions of the material.
● With its vertical-axis 1.6 fold hook, the frequency of bobbin thread
replacement is reduced. This hook increases efficiency and offers
special advantages when using thick threads.
● PLC-1610-7
The machine is provided with a highly reliable thread trimmer that cuts
thick thread without fail. No need for additional adjustment even
when thread number count is changed.
PLC-1610
PLC-1610-7
(with automatic thread trimmer)
1-needle, Post-bed, Unison-feed, Lockstitch Machine
Model name
Max. sewing speed
Max. stitch length
Needle bar stroke
Lift of the presser foot
Auto lifter
Thread take-up
Alternating vertical movement
Hook
Needle (at the time of delivery)
Thread
Lubrication
Lubricating oil
Compressed air and air consumption
Safety mechanism
Bobbin winder
Post height
Bed size
Weight of the machine head
Automatic reverse feed function
Power requirement
PLC-1610 PLC-1610-7
2,000rpm
6mm (normal/reverse feed)
33.4mm
By hand: 10mm, Auto: 15mm
Provided as standard (pneumatic auto-lifter: AK116)
Slide type
2〜8mm
Vertical-axis 1.6 fold-capacity hook
134×35 (Nm140) Nm110〜Nm160 (equivalent to #22, #18〜#23 )
#30〜#5, B46〜B138, Nm=60/3〜15/3
By an oiler
JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
0.5MPa (5kgf/cm
2
), 0.3N /min
Provided as standard
Built on the machine arm
161.7mm
517mm×178mm
48kg 50kg
― Provided as standard
―
Single-phase 100〜120V, 220〜240V
3-phase 200〜220V, 220〜240V
