LH-3162-7, 3182-7 (September, 2003) 1/2
Model Part No. Description Feature
AK89
―
―
―
227-98458
227-97252
227-98508
EA-9500B0100
227-98052
Auto-lifter
Compensation stitching switch
(reverse feed control lever mounting type)
Compensation stitching switch
(foot switch type)
―
Works effectively when you need to perform sewing while changing the
stitch length of the compensation stitch (one stitch).
Works effectively when you want to control the compensation stitching
(one stitch) by foot.
OPTIONS
LH-3182-7/CP-660B
Model name
Application
Max. sewing speed
Max. stitch length
Lift of the presser foot
Hook
Needle (at the time of delivery)
Thread take-up
Needle bar stroke
Lubrication
Lubricating oil
Organized split needle bar
Distance from needle to machine arm
Bed size
Weight of the machine head
Power requirement
● The automatic organized split needle bar releasing device automatically
counts the number of stitches and releases the needle bar from the stop
state. Since the operator only needs to press the switch once at the
start of corner stitching, operator can concentrate on the handling of
the material being sewn. This upgrades efficiency dramatically.
● To sew several corners of a material continuously, a series of corner
stitching processes can be automatically performed by creating a sewing
program which combines different types of corner stitching processes.*
As many as eight different corner stitching processes and eight different
patterns can be combined in a sewing program.
* If your machine is equipped with JUKI’s unique reverse function
(pattern inverting function), as many as 16 different corner stitching
processes can be combined.
● The machine is able to sew continuous obtuse-angle corners (gentle
corners). Since the machine can perform same pattern sewing in
repetition, it allows the operator to continuously sew gentle corners of
a skirt (sewing in repetition) only by operating the knee switch.
2-needle, Needle-feed, Lockstitch Machine
with Automatic Organized Split Needle Bar Incorporating Corner
Programming Device and Automatic Thread Trimmer
SPECIFICATIONS
LH-3162-7
LH-3182-7
(with large hooks)
LH-3162A-7
For light-weight materials
LH-3162S-7
For medium-weight
materials
3,000rpm
5mm (normal/reverse feed)
By hand: 5.5mm, By knee: 12mm, By knee lifter with wiper: 9mm
Vertical-axis regular hook (cap type)
DP×5 (#11) #11〜#14 DP×5 (#14) #11〜#18 DP×5 (#21) #18〜#22, For JE: 134 (Nm130)
Slide type
33.4mm
Fully automatic lubrication system by means of plunger pump
JUKI New Defrix Oil No.2 (equivalent to ISO VG32)
Provided as standard
245mm
517mm×178mm
43Kg
Single-phase 100〜120V, 200〜240V, 3-phase 200〜240V
LH-3162G-7 LH-3182G-7
For jeans and heavy-weight materials
Vertical-axis double-
capacity hook (cap type)
Compensation stitching switch
(reverse feed control lever
mounting type)
Compensation stitching switch
(foot switch type)
To Next Page
