MO-6900G Series (September, 2003) 1/2
SUBCLASS MACHINE LIST
Bottom-feed, Overlock / Safety Stitch Machine
for Extra heavy-weight materials
M
O
-6900G Series
MO-6916G
Model name MO-6904G MO-6914G MO-6916G
Stitch type 1-needle overlock 2-needle overlock Safety stitching
Stitch style in the U.S.A. 504 514 516
Max. sewing speed 6,000rpm
Stitch length 2.5〜5mm 2.5〜4mm 2.5〜5mm
Needle gauge (mm) − 2.6 4.8
Overedging width (mm) 4.8, 10.0, 18.0 6.4 4.8, 6.4
Differential feed ratio
For gathering 1:1.75 (max. 1:3.8) For gathering 1:2 (max. 1:3.8) For gathering 1:1.75 (max. 1:3.8)
For stretching 1:0.7 (max. 1:0.6) For stretching 1:0.8 (max. 1:0.6) For stretching 1:0.7 (max. 1:0.6)
Needle bar stroke 28.8mm
Inclination angle of the needle 20°
Needle bar bushing Upper/lower bushing method
Needle DO×5 (excluding some subclass model)
Max. lift of the presser foot 8mm (excluding some subclass model)
Max. presser foot pressure 63.7N (6.5kg)
Stitch adjusting method By push-button
Differential-feed adjusting method By lever (with micro-adjustment)
Weight of the machine head 28kg
Lubrication Automatic
Lubricating oil JUKI Machine Oil 18 (equivalent to ISO VG18)
Needle cooler Provided as standard (excluding some subclass model)
Needle thread heat remover Provided as standard
Micro-lifter Provided as standard
MO-6903G-0N6-3D1 L〜M1 2 − 18.0 3 7 −−5DO×5 #16 5,500 For splicing fabrics
MO-6904G-0F6-700 1 3 − 4.8 3 5 1:0.7〜1:1.75 − 8DO×5 #21 6,000
For runstitching
extra heavy- weight
materials such as denim
MO-6905G-0M6-700 1 3 − 10.0 3 7 −−7DC×1 #24 4,000
For overedging carpets,
mats for entrance halls, etc.
MO-6905G-0M6-7E0
EH
13− 10.0 3 7 −−7DC×1 #24 4,000 For overedging car mats
MO-6914G-CH6-700 2 4 2.6 6.4 3 4 1:0.8〜1:2 − 8DO×5 #18 6,000 For overedging jersey, etc.
MO-6916G-FF6-700 2 5 4.8 4.8 3 5 1:0.7〜1:1.75 − 8DO×5 #21 6,000
MO-6916G-FH6-700 2 5 4.8 6.4 3 5 1:0.7〜1:1.75 − 8DO×5 #21 6,000
For safety stitching
extra heavy-weight
materials such as denim
Model No.
Materials
Number
of
needles
Number
of
threads
Needle
gauge
(mm)
Overedging
width (mm)
Number
of
feed dog
rows
Stitch
length
(mm)
Presser
lifting
amount
(mm)
Needle system
Max.
sewing
speed
(rpm)
Bottom
differential-
feed ratio
Remarks
Longitudinal
stroke
of top-feed
dog (mm)
● The machine incorporates a mechanism and parts that are optimum
for the sewing of extra heavy-weight materials, such as an extra
high-lift type upper looper, tractor foot and coarse type feed dog.
It demonstrates an excellent performance ability in the sewing of
various kinds of heavy-weight materials such as jeans, raised fabric
materials, mats and carpets.
● The machine securely clamps the material at the beginning of sewing
as well as smoothly sewing multi-layered parts of the material to
facilitate the sewing of extra heavy-weight materials.
SPECIFICATIONS
