Jupiter AX411 Access Point User Manual

APPENDIX D
AX411 Access Point Interface Cable
Specifications and Connector Pinouts
This section includes the following topics:
•
Interface Cable and Wire Specifications for the AX411 Access Point on page 101
•
RJ-45 Connector Pinouts for the AX411 Access Point Ethernet Port on page 101
•
RJ-45 Connector Pinouts for the AX411 Access Point Console Port on page 102
Interface Cable and Wire Specifications for the AX411 Access Point
Table 23 on page 101 lists the specifications for the cables that connect to ports on the
AX411 Access Point.
Table 23: Cable and Wire Specifications for Ports and on the AX411 Access
Point
Device
ReceptacleMaximum LengthCable SpecificationPort
RJ-456 ft (1.83 m)RS-232 (EIA-232) serial cableConsole port
RJ-45328 ft (100 m)Category 5e or Category 6 cable or
equivalent suitable for 1000Base-T
and PoE operation
Ethernet port
Related
Documentation
RJ-45 Connector Pinouts for the AX411 Access Point Ethernet Port on page 101•
• RJ-45 Connector Pinouts for the AX411 Access Point Console Port on page 102
RJ-45 Connector Pinouts for the AX411 Access Point Ethernet Port
The Ethernet port on the front panel is an autosensing 10/100/1000-Mbps Ethernet
RJ-45 receptacle that accepts an Ethernet cable for connecting the access point to the
SRX Series device that manages it.
Figure 13 on page 102 shows the RJ-45 cable connector.
101Copyright © 2012, Juniper Networks, Inc.
