Keithley 2001 User Manual

IEEE-488 Reference
4-169
4.21
:STATus subsystem
The STATus subsystem is used to control the status registers of the Model 2001. These registers
and the overall status structure is explained in paragraph 4.6.
The commands in this subsystem are summarized in Table 4-28.
Table 4-28
STATus command summary
Command Description Reference
:STATus
:MEASurement
[:EVENt]?
:ENABle <NRf>
:ENABle?
:PTRansition <NRf>
:PTRansition?
:NTRansition <NRf>
:NTRansition?
:CONDition?
:OPERation
[:EVENt]?
:ENABle <NRf>
:ENABle?
:PTRansition <NRf>
:PTRansition?
:NTRansition <NRf>
:NTRansition?
:CONDition?
:ARM
[:EVENt]?
:ENABle <NRf>
:ENABle?
:PTRansition <NRf>
:PTRansition?
:NTRansition <NRf>
:NTRansition?
:CONDition?
:SEQuence
[:EVENt]?
:ENABle <NRf>
:ENABle?
:PTRansition <NRf>
:PTRansition?
:NTRansition <NRf>
:NTRansition?
:CONDition?
Path to control measurement event registers:
Read the event register.
Program the enable register.
Read the enable register.
Program the positive transition register.
Read the positive transition register.
Program the negative transition register.
Read the negative transition register.
Read the condition register.
Path to control operation event registers:
Read the event register.
Program the enable register.
Read the enable register.
Program the positive transition register.
Read the positive transition register.
Program the negative transition register.
Read the negative transition register.
Read the condition register.
Path to control arm event registers:
Read the event register.
Program the enable register.
Read the enable register.
Program the positive transition register.
Read the positive transition register.
Program the negative transition register.
Read the negative transition register.
Read the condition register.
Path to control the sequence event registers:
Read the event register.
Program the enable register.
Read the enable register.
Program the positive transition register.
Read the positive transition register.
Program the negative transition register.
Read the negative transition register.
Read the condition register.
4.21.1
4.21.2
4.21.3
4.21.4
4.21.5
4.21.1
4.21.2
4.21.3
4.21.4
4.21.5
4.21.1
4.21.2
4.21.3
4.21.4
4.21.5
4.21.1
4.21.2
4.21.3
4.21.4
4.21.5
