Keithley 2001 User Manual

IEEE-488 Reference
4-183
Effects of positive transitions on the Questionable Event Register:
Positive transition effect on
Questionable event Questionable Event Register
Temperature summary Sets B4 when an invalid reference junction measurement has oc-
curred.
Calibration summary Sets B8 when an invalid calibration constant is detected on power-up.
Command warning Sets B14 when a Signal Oriented Measurement Command parameter
is ignored.
F
igure 4-35
Questionable Transition Filter
Bit Position
Event
Decimal Weighting
Value
Value : 1 = Enable Positive Transition
0 = Disable Positive Transition
A) Positive Transition (PTR) Register
Bit Position
Event
Decimal Weighting
Value
Value : 1 = Enable Negative Transition
0 = Disable Negative Transition
B) Negative Transition (NTR) Register
Cal
B13 - B9 B8B15 B14
(2 )
8
25
6
(2 )
14
16384
0/10/1
Warn
B7 - B5
0
Temp
B4
(2 )
4
16
0/1
B3 - B0
Cal
B13 - B9 B8B15 B14
(2 )
8
256
(2 )
14
16384
0/10/1
Warn
B7 - B5
0
Temp
B4
(2 )
4
16
0/1
B3 - B0

Keithley 2001 Specifications

General

Model	2001
Category	Multimeter
Manufacturer	Keithley
Type	Digital Multimeter
Digits of Resolution	7.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Connectivity	GPIB, RS-232
Display	VFD
Resistance Accuracy	0.008% + 2.0 mΩ
Frequency Accuracy	±0.01%
DC Current Range	10 μA to 3 A
AC Current Range	10 μA to 3 A
Power Supply	100 V to 240 V AC, 45 Hz to 66 Hz
