2600S-901-01 Rev. C / January 2008 Return to Section Topics 2-17
Series 2600 System SourceMeter® Instruments Reference Manual Section 2: TSP Programming
The toolbar at the top of the Test Script Builder is used to save the displayed script file. As
explained in
Figure 2-9, the script file can be saved in the same folder and/or saved in a different
folder.
Figure 2-9
Saving a script in the Test Script Builder
Click File and then click Save in the the drop-down menu.
OR
To save the displayed script file in the same project folder:
Click the diskette icon.
To save the displayed script file in a different project folder:
A) Click File and then click Save As in the the drop-down menu to
display the Save As window.
B) In the Save As window:
1. Select (click) the project folder for the script file.
2. If desired, change the name of the script File name. The .esp
extension must be included in the file name.
Creating new script files
A script project can be made up of one or more script files. Figure 2-10 shows how to add a script
file to a project folder.
