Kenwood DNX6180 User Manual

87
Return to the Top page
Audio Setting Up
Controlling equalizer manually
1
Touch [Tone] in the Equalizer screen.
2
Set each item as follows.
FREQ
Adjusts the center frequency for each range.
Setting values are as follows.
Bass: 40Hz/50Hz/60Hz/70Hz/80Hz/100Hz/120
Hz/150Hz (Default is “100Hz.”)
Middle: 500Hz/1kHz/1.5kHz/2kHz (Default is
“1kHz.”)
Treble: 10kHz/12.5kHz/15kHz/17.5kHz (Default
is “12.5kHz.”)
LEVEL
Adjusts the level of each range.
Each setting value is within -8dB and 8dB and
default is “0dB.”
Q Factor
Adjust Q value for bass and middle.
Setting values are as follows.
Bass: 1/1.25/1.5/2 (Default is “1.”)
Middle: 1/2 (Default is “1.”)
Bass DC EXT
Turns Bass DC EXT on or off. Default is “OFF.”
If you select “ON”, the bass center frequency is
extended to the low register by approximately
20%.
[Flat]
Tone level becomes 0 (flat).
Subwoofer Level
Adjusts the subwoofer volume. This setting is
not available when subwoofer is set to “None”.
See Speaker setup (P.81).
Zone Control
You can select different sources for both
front and rear positions in the vehicle.
1
Touch [Zone Control].
Zone Control screen appears.
2
Touch [Dual Zone].
3
Set each source as follows.
[3] (Front Source, Rear Source)
Select the audio source for each.
[∞], [5] (Rear VOL.)
Adjusts the rear channel volume.
[Single Zone]
Touch to turn off the dual zone function.
Continued
