Komatsu PC20R-8 User Manual

176
TECHNICAL DATA
5.1.5 LIFTING CAPACITY WITH CAB
(for model PC20R only)
CAUTION
• According to the standard EN474-5 (§ 4.1.7.5), this machine if not equipped with suitable devices is not
allowed to lift more than 1000 kg.
• Do not attempt to lift loads unless the machine is standing on firm, level ground.
: Rating over front
: Rating at maximum reach
❈
: Load is limited by hydraulic
capacity rather than tipping
A - Reach from swing center
B - Bucket hook height
C - Lifting capacity
C
B
A
3 m 2 m
2m
1m
0
-1m
370 310 ❇ 525 500 ❇ 860 ❇ 850
340 300 530 460 875 860
340 320 500 460 880 850
350 330 510 475 900 875
Arm
lenght
1070mm
1320mm
330 270 460 410 825 800
C
0
: Rating over side
C
B
A
kg
L
Bucket width L= 400mm
Bucket weight kg 48
> 1000 kg
Do not lift more than 1000 kg
RWA09450
