65

INSTRUMENTS AND CONTROLS

3.3.4 ELECTRICAL ACCESSORIES

1 - Engine acoustic alarm

2 - Windshield wiper / washer switch

(with cab only)

3 - Overhead lamp

(with cab only)

4 - Electric outlet

RYA12070

2

RYA12080

3

RYA12090

4

RYAA0010

1
