TECHNICAL DATA
5.1.7 LIFTING CAPACITY WITH CAB
(for model PC27R only)
CAUTION
• According to the standard EN474-5 (§ 4.1.7.5), this machine if not equipped with suitable devices is not
allowed to lift more than 1000 kg.
• Do not attempt to lift loads unless the machine is standing on firm, level ground.
: Rating over front
: Rating at maximum reach
❈
: Load is limited by hydraulic
capacity rather than tipping
A - Reach from swing center
B - Bucket hook height
C - Lifting capacity
: Rating over side
C
B
A
kg
L
Bucket width L= 400mm
Bucket weight kg 52
> 1000 kg
RWA09670
▲
: Load is limited according to
the standard EN474-5
(§4.1.7.5)
C
B
A
4 m 3 m 2 m
2m
1m
0
-1m
370 ❇ 375 340 330 580 ❇ 550 ❇ 860 ❇ 550
340 320 ❇ 380 320
680 550 ▲ 990 ❇ 650
❇ 370 300 ❇ 370 310 ❇ 665 540
▲ 990 840
390 310 ❇ 380 320
700 560 ❇ 865 860
Arm
lenght
1200mm
1500mm
310 260 ❇ 330 300 ❇ 610 525 ▲ 990 800
C
0
