• According to the standard EN474-5 (§ 4.1.7.5), this machine if not equipped with suitable devices is not
allowed to lift more than 1000 kg.
• Do not attempt to lift loads unless the machine is standing on firm, level ground.
: Rating over front
: Rating at maximum reach
❈
: Load is limited by hydraulic
capacity rather than tipping
A - Reach from swing center
B - Bucket hook height
C - Lifting capacity
C
B
A
3 m 2 m
2m
1m
0
-1m
360 300 ❇ 525 485 ❇ 860 ❇ 850
330 290 510 440 850 840
330 305 480 440 860 830
335 320 490 450 880 850
Arm
lenght
1070mm
1320mm
320 260 440 395 800 780
C
0
: Rating over side
C
B
A
kg
L
Bucket width L= 400mm
Bucket weight kg 48
> 1000 kg
Do not lift more than 1000 kg
RWA09560
