INSTRUMENTS AND CONTROLS
2 - WORKING LIGHT AND INSTRUMENT LIGHT
SWITCH
3 - IGNITION SWITCH
4 - BOOM OVERLOAD ALARM SWITCH
(if installed)
5 - REVOLVING LIGHT SWITCH
(if installed)
RWA07180
This is a rotary switch with three positions marked by the follow-
ing symbols: (OFF - 1 - 2).
1) Enables the instrument light circuit
2) Enables the working light circuit
This is a rotary key switch with four positions marked by the fol-
lowing symbols: «» - (OFF) - I - «» (START).
For the use of this switch, see “3.6.2 STARTING THE ENGINE”).
RWA23290
This is a rotary switch with two positions (OFF - ON) and, if oper-
ated, makes it possible to define when the capacity limit has
been reached.
RWA07200
This is a tow-position rotary switch and, if pressed, operates the
revolving light.
RWA07210
