SAFETY, NOISE AND VIBRATION PLATES
22
2.1.2 PICTOGRAMS AND RELEVANT MEANINGS
DANGER IN THE WORK AREA
DO NOT OPEN THE HOOD
CONSULT THE MANUAL
HYDRAULIC OIL TOPPING UP
The warning and danger plates applied onto the machine are accompanied or represented by pictograms.
The personnel in charge with the operation and maintenance of the machine must know the symbols contained in
the pictograms perfectly; the following description illustrates what they look like and their respective meanings.
RWA00020
• Do not approach or stand within the equipment operating radi-
us when the boom and the bucket are raised.
RWA00010
• Do not open or remove the hood when the engine is running.
RWA00030
• Carefully read the contents of the manual before using the ma-
chine or performing maintenance operations.
