Komatsu PC210 User Manual

2-61
PC210/240-ENG
12.5 STEERING MACHINE
12.5.1 STEERING (changing direction)
WARNING
Before operating the travel levels, check the position of the
sprocket. If the sprocket is at the front, the operation of the travel
levels is reversed.
Use the travel levers to change direction.
Avoid sudden changes of direction as far as possible. In particular,
when carrying out counter-rotation (spin turn), stop the machine first be-
fore turning.
Operate two travel levers a as follows.
Changing direction of machine when stopped
When turning to the left:
Push the right travel lever forward to travel left when travelling for-
ward; and pull it back to turn left when travelling in reverse.
REMARK
When turning to the right, operate the left travel lever in the same
way.
Steering when travelling (left and right travel levers both operated in
same direction)
When turning to the left:
If the left travel lever is returned to the neutral position, the machine
will turn to the left.
REMARK
When turning to the right, operate the right travel lever in the same
way.
12. OPERATION

Komatsu PC210 Specifications

General

Bucket Capacity	0.8 - 1.2 m³
Travel Speed	5.5 km/h
Max Digging Depth	6, 620 mm
Max Reach	9, 850 mm
Fuel Tank Capacity	400 l
Engine Model	Komatsu SAA6D107E-1
