12.17 PARKING THE MACHINE
WARNING
• Avoid stopping suddenly. Give yourself ample room when
stopping.
• When stopping the machine, select flat hard ground and avoid
dangerous places. If it is unavoidably necessary to park the
machine on a slope, insert chocks underneath the wheels. As
an additional safety measure, thrust the bucket into the
ground.
• If the control lever is touched by accident, the work equipment
or the machine may move suddenly, and this may lead to a
serious accident. Before leaving the operator’s compartment,
always set the safety lock lever securely to LOCK position.
1. Put left and right levers a in the neutral position.
The machine stops.
2. Turn fuel control dial b to lower the engine speed to low idling.
12. OPERATION

Komatsu PC210 Specifications

General

Bucket Capacity	0.8 - 1.2 m³
Travel Speed	5.5 km/h
Max Digging Depth	6, 620 mm
Max Reach	9, 850 mm
Fuel Tank Capacity	400 l
Engine Model	Komatsu SAA6D107E-1
