Komatsu PC210 User Manual

2-73
PC210/240-ENG
12. OPERATION
12.13 PRECAUTIONS WHEN TRAVELLING UP
OR DOWN HILLS
WARNING
• When travelling, raise the bucket approx. 20 - 30 cm (8 -12 in)
from the ground.
Do not travel downhill in reverse.
• When travelling over ridges or other obstacles, keep the work
equipment close to the ground and travel slowly.
• It is dangerous to turn on slopes or to travel across slopes.
Always go down to a flat place to perform these operations. It
may be longer, but it will ensure safety.
• If the machine starts to slide or loses stability, lower the
bucket immediately and brake the machine.
• Turning or operating the work equipment when working on
slopes may cause the machine to lose its balance and turn
over, so avoid such operations. It is particularly dangerous to
swing downhill when the bucket is loaded.
If such operations have to be carried out, pile soil to make
platform on the slope so that the machine can be kept hori-
zontal when operating.
• Do not travel on slopes of over 30
o
as there is danger that the
machine may overturn.
1) When travelling down steep hills, keep the travel speed low.
When travelling down slopes of more than 15
o
, set the work equip-
ment in the posture shown in the figure on the right, and lower the
engine speed.
2) When travelling up a steep hill of more than 15
o
, set the work equip-
ment in the posture shown in the diagram on the right.

Komatsu PC210 Specifications

General

Bucket Capacity	0.8 - 1.2 m³
Travel Speed	5.5 km/h
Max Digging Depth	6, 620 mm
Max Reach	9, 850 mm
Fuel Tank Capacity	400 l
Engine Model	Komatsu SAA6D107E-1
